9.1.3 Mechanical Specification
Item Specification
Radome Height 770 mm (30.3")
Radome Diameter Ø845 mm (33.3")
Reflector Size 73 cm (28.7")
Radome Color White
Antenna Safety Gap 15 mm
Antenna Weight
< 34 kg (75.0 lbs) with Radome
33.6 kg (74.1 lbs) for Primary, 32.5 kg (71.7 lbs) for Secondary
Primary Secondary
Package
(Single
stack)
Size
900 mm x 900 mm x 1070 mm
(L x W x H)
900 mm x 900 mm x 1070 mm
(L x W x H)
Package weight
(Antenna+
Package+HM)
Approx. 66 kg Approx. 63 kg
Package
(Double
stack)
Size 900 mm x 900 mm x 2140 mm (L x W x H)
Package weight
(Antenna+
Package+HM)
Approx. 129 kg
Package
(Single
stack)
Size
900 mm x 900 mm x 1070 mm
(L x W x H)
900 mm x 900 mm x 1070 amm
(L x W x H)
Package weight
(Antenna+Package)
Approx. 64 kg Approx. 61 kg
Package
(Double
stack)
Size 900 mm x 900 mm x 2140 mm (L x W x H)
Package weight
(Antenna+Package)
Approx. 125 kg
※ Package size may change with design revisions
