OW70L-Dac - OneWeb LEO User Terminal
16
Before starting installation, make sure you have all the included components.
The following components are added to (with Heating Module) each package.
Heating Module Accessories for OW70LH-Dac (with Heating Module)
Primary Antenna Package (Box 1)
Item Q'ty Size Description
F-type Connector Adaptor 1
Convert Power Adaptor connector to F-Type
(Female Coax connector for RG11)
Power Adapter (AC-DC) For
Heating Module
1
To convert 100-240 V AC power to +56 V DC for
Heating Module (250 W)
AC Power Cord (USA) 1 1.5 m AC Power Cord (110 V)
AC Power Cord (CEEE7/7) 1 1.5 m AC Power Cord (220 V)
Primary Antenna Package (Box 2)
Item Q'ty Size Description
F-type Connector Adaptor 1
Convert Power Adaptor connector to F-Type
(Female Coax connector for RG11)
Power Adapter (AC-DC) For
Heating Module
1
To convert 100-240 V AC power to +56 V DC for
Heating Module (250 W)
AC Power Cord (USA) 1 1.5 m AC Power Cord (110 V)
AC Power Cord (CEEE7/7) 1 1.5 m AC Power Cord (220 V)
NOTE
• The Heating Module are assembled and tested at the Primary and Secondary Antenna during
production.
• The accessories of heating module are packed in each package box.
• The separate purchased RG11 Coax cable are necessary to connect the Heating Module and the Power
adapter.
4.4 Installer/Customer Furnished Equipment
• Country specific power cable and socket for Power Adaptors
• Grounding system that meets the local electrical code requirements
• Waterproofing materials all connections
• Tape or wraps to attach the antenna cable to the support structurer
• Fasteners and other installation tools
