Intellian OW70L-Dac User Manual

OW70L-Dac - OneWeb LEO User Terminal
52
Item Specification
EGR
GPS L1 Frequency 1574.397 – 1576.443 MHz
GLONASS Frequency 1597.5515 – 1605.886 MHz
Communication
Protocol
NMEA 0183
Reference Clock
Frequency
10MHz sinusoidal reference clock output to the MIM
Supply Voltage Min. 5.2 V, Max. 5.8 V
Power Consumption Max. 8 W
Antenna Power
Interface
Min. 3 V, Max. 5 V
Surge Protection Max. 2 kV
Connections SMA
Digital Signals
Tx-ON : LVDS
Rx-ON : LVDS
Frequency Reference: LVDS
Reset: LVDS
Ant. Monitor, Control Interface Ethernet, 10/100 Base T
CNX
Antenna Subsystem
Interface
Four GigE RJ-45 Ethernet
Encryption
MoCA 2.0
E-band (400-700MHz)
Input Voltage Min. 52 V, Max. 59 V
Operating Power Max. 30 W
Output Voltage 56 VDC
Output Power Max. 220 W
Reset MoCA chipset and Ethernet PHY
LEDs
Power:
Operational – Solid GREEN
Fault Condition – Solid RED
Operating with Backup S/W – Blinking RED
Off – No power
Ethernet:
Ready – Solid GREEN
Activity – Blinking GREEN
Off – No device connected or device connected not operational
Internet:
Operational – Solid GREEN
(CNX-MIM MoCA connected)
Fault Condition – Solid RED
Antenna Subsystem
Interface
Four GigE RJ-45 Ethernet
Tx Cable LMR 400: Tx IF + 25 MHz reference signal
Rx Cable LMR 400: 2 GHz IF + Power
Ethernet Cable CAT5
