Intermec EasyCoder PD41 User Manual

Appendix E — Interfaces
EasyCoder PD41 Printer User’s Guide 93
14 nAutoFd
15-16 Not connected
17 Chassis ground
18 External +5V DC Max 500mA
19-30 Signal ground
31 nInit
32 nFault printer
33 Signal ground
34-35 Not connected
36 nSelectln
Pinout Description
Pin Function Transmitter Comment

Intermec EasyCoder PD41 Specifications

General

Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Standard interfaces	RS-232, USB 2.0
Internal memory	16 MB
Power requirements	100-240 VAC ±10%, 45-65 Hz
Media thickness	2.3 - 9.8 mm
Maximum label width	104 mm
Maximum label length	0.15 m
Maximum roll diameter	213 mm
Maximum internal memory	1 GB
Supported network protocols	TCP/IP, LPR/LPD, FTP, BOOTP, DHCP, HTTP, SNMPv3, SMTP, SNMP-MIB II
Operating temperature (T-T)	40 - 104 °F
Operating relative humidity (H-H)	20 - 85 %

Weight and Dimensions

Depth	453 mm
Width	273 mm
Height	270 mm
Weight	13000 g
