Intermec EasyCoder PD41 User Manual

Appendix D — Setup Parameters (IPL)
EasyCoder PD41 Printer User’s Guide 83
characters. The printer responds to each status inquiry or message
block with the printer status. The host should check the printer
status before downloading a message block to the printer. ENQ
causes the printer to transmit its highest priority status, while VT
instructs the printer to transmit all status that applies in the order
of their priority. The possible printer status in descending
priorities are
Media Setup
The media parameters tell the firmware the characteristics of the
media that will be used, so the printout will be positioned
correctly with optimal quality.
Media Type
The Media Type parameters control how the label stop sensor
(LSS) and the media feed work. There are three media type
options:
• Gap is used for adhesive labels mounted on liner (backing
paper) or continuous paper stock with detection slots.
Default.
• Mark is used for labels, tickets, or strip provided with black
marks at the back.
• Continuous is used for continuous stock without any
detection slots or black marks.
Condition Character
Buffer already full GS
Printhead raised US
Ribbon fault US
No label stock EM
Buffer now full DC3
Printhead hot SI
Label at strip pin FS
Label skipping DC1
Ready DC1
Printing DC1

Intermec EasyCoder PD41 Specifications

General

Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Standard interfaces	RS-232, USB 2.0
Internal memory	16 MB
Power requirements	100-240 VAC ±10%, 45-65 Hz
Media thickness	2.3 - 9.8 mm
Maximum label width	104 mm
Maximum label length	0.15 m
Maximum roll diameter	213 mm
Maximum internal memory	1 GB
Supported network protocols	TCP/IP, LPR/LPD, FTP, BOOTP, DHCP, HTTP, SNMPv3, SMTP, SNMP-MIB II
Operating temperature (T-T)	40 - 104 °F
Operating relative humidity (H-H)	20 - 85 %

Weight and Dimensions

Depth	453 mm
Width	273 mm
Height	270 mm
Weight	13000 g
