Chapter 1 — Getting Started
EasyCoder PD41 Printer User’s Guide 7
Media Compartment
EasyCoder PD41: Media Compartment
Print Mechanism
EasyCoder PD41: Print Mechanism
Ribbon rewind shaft
Ribbon supply shaft
Media supply post
Edge guide
Ink position lever
Label taken
sensor
Media
feed
rods
Printhead
lever
Tear bar
Printhead
balance boxes
Thermal printhead
Ribbon
rod
