Intermec EasyCoder PD41 User Manual

Appendix A — Technical Data
EasyCoder PD41 Printer User’s Guide 55
Resident scaleable fonts 15
Character Sets • 23 single-byte character sets standard.
• UTF-8 support as standard.
Resident Bar Codes 61
Firmware (IPL)
Operating System IPL v10.0.X
Smooth Fonts TrueType and TrueDoc fonts
Resident scaleable fonts 13 (+21 simulated bitmap)
Character sets • 23 single-byte character sets standard.
• UTF-8 support as standard.
Resident Bar Codes 31
Environment
Operating temperature +5°C to +40°C (+41°F to 104°F)
Storage temperature -20°C to 70°C (-4°F to 122°F)
Operating Humidity 20 to 80% non-condensing
Storage Humidity 10 to 90% non-condensing
Media
Media width 25 to 118 mm (1 to 4.65 inches)
Max 114mm (4.49 in.) with cutter.
Media Roll diameter 213 mm (8.35 in.) max.
190 mm (7.5 in.) with internal rewinder.
Internal Rewinder
diameter
Max 140 mm (5.51 in.)
Media Roll Core
Diameter
38.1 to 76.2 mm (1.5 to 3 in.)
Media Thickness 60 μm to 250 μm (2.3 to 9.8 mils)
Transfer Ribbon
Material Wax, hybrid, or resin
Winding Ink on either inside or outside of roll
Ribbon width 30 to 110 mm (1.18 to 4.33 in.)
Ribbon Roll Diameter
(outer)
76 mm (2.99 in.) equivalent to 450 meters
(1471 ft) of ribbon.
Inner core Diameter 25.2 to 25.6 mm (1
in.)
Printer Specifications Table

Intermec EasyCoder PD41 Specifications

General

Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Standard interfaces	RS-232, USB 2.0
Internal memory	16 MB
Power requirements	100-240 VAC ±10%, 45-65 Hz
Media thickness	2.3 - 9.8 mm
Maximum label width	104 mm
Maximum label length	0.15 m
Maximum roll diameter	213 mm
Maximum internal memory	1 GB
Supported network protocols	TCP/IP, LPR/LPD, FTP, BOOTP, DHCP, HTTP, SNMPv3, SMTP, SNMP-MIB II
Operating temperature (T-T)	40 - 104 °F
Operating relative humidity (H-H)	20 - 85 %

Weight and Dimensions

Depth	453 mm
Width	273 mm
Height	270 mm
Weight	13000 g
