Intermec EasyCoder PD41 User Manual

Chapter 5 — Setting up the Printer
EasyCoder PD41 Printer User’s Guide 47
Extended Testmode
The extended testmode can be used to run additional tests. This
includes the option to print test labels, running a testfeed in slow
mode, entering dump mode and resetting to factory defaults.
The extended Testmode is entered by raising the printhead, and
switching power on while keeping the Print button pressed.
Extended Testmode will run a sequence which can be controlled
via the Print button, and raising or lowering the printhead. The
sequence of steps in the Extended Testmode follows in the table:
Testmode: Running the Dump mode
Step
Data/
Ready Error RtW Button Comment
6 The printer is now in Dumpmode and the printer scans the
communication ports. The printer will print any characters it
received on the communication ports to a label when exiting
dump mode.
7 Tap the button once to exit Dumpmode. If you tap the button
within two seconds of entering dump mode, no labels are
printed.
8 1 1 The printer will start as on
rebooted status. When
operational, Data/Ready
and RtW will be lit.
Extended Testmode: Activating
Step
Data/
Ready
Error RtW Button Comment
1 1 Make sure the printhead is
lifted. Press and hold the
Print button and switch the
printer On. Extended
Testmode is activated after
10 seconds.
2 flash flash flash All 3 LEDs flash rapidly four
times. Extended Testmode is
activated. Release button to
continue.

Intermec EasyCoder PD41 Specifications

General

Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Standard interfaces	RS-232, USB 2.0
Internal memory	16 MB
Power requirements	100-240 VAC ±10%, 45-65 Hz
Media thickness	2.3 - 9.8 mm
Maximum label width	104 mm
Maximum label length	0.15 m
Maximum roll diameter	213 mm
Maximum internal memory	1 GB
Supported network protocols	TCP/IP, LPR/LPD, FTP, BOOTP, DHCP, HTTP, SNMPv3, SMTP, SNMP-MIB II
Operating temperature (T-T)	40 - 104 °F
Operating relative humidity (H-H)	20 - 85 %

Weight and Dimensions

Depth	453 mm
Width	273 mm
Height	270 mm
Weight	13000 g
