Intermec EasyCoder PD41 User Manual

Appendix B — Media Specifications
62 EasyCoder PD41 Printer User’s Guide
Self-Adhesive Labels
* This is the print length limit set by memory constraints.
The Label Gap sensor must be able to detect the front edges of
the labels. It can be moved 0 to 57 mm (0 to 2.24 inches) from
the inner edge of the media.
Paper Type Setup
• Labels with Gaps
a: Media Width
Maximum: 118.0 mm 4.65 inches
Minimum: 25.0 mm 1.00 inches
b: Liner
The liner must extend evenly on both sides and not more than a total
of 1.6 mm (0.06) inches outside the face material.
c: Label Width (excluding liner)
Maximum: 116.4 mm 4.58 inches
Minimum: 23.8 mm 0.94 inches
d: Label Length Fingerprint IPL
8 dots/mm (203 dpi)
Maximum: 1270 mm (50 in.)* 600 mm (23 in.)
Minimum: 6 mm (0.2 in.) 6 mm (0.2 in.)
11.81 dots/mm (300 dpi)
Maximum: 558.8 mm (22 in.)* 406.4 mm (16 in.)
Minimum: 6 mm (0.2 in.) 6 mm (0.2 in.)
e: Label Gap
Maximum: 26.0 mm 1.02 inches
Minimum: 1.2 mm 0.05 inches
Recommended: 3.0 mm 0.12 inches

Intermec EasyCoder PD41 Specifications

General

Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Standard interfaces	RS-232, USB 2.0
Internal memory	16 MB
Power requirements	100-240 VAC ±10%, 45-65 Hz
Media thickness	2.3 - 9.8 mm
Maximum label width	104 mm
Maximum label length	0.15 m
Maximum roll diameter	213 mm
Maximum internal memory	1 GB
Supported network protocols	TCP/IP, LPR/LPD, FTP, BOOTP, DHCP, HTTP, SNMPv3, SMTP, SNMP-MIB II
Operating temperature (T-T)	40 - 104 °F
Operating relative humidity (H-H)	20 - 85 %

Weight and Dimensions

Depth	453 mm
Width	273 mm
Height	270 mm
Weight	13000 g
