Chapter 1 — Getting Started
EasyCoder PD41 Printer User’s Guide 5
Controls and Indicators
Front panel: LEDs and the Print button.
The blue button on the front panel is the Print button, which
also functions as a control button in Testmode. The significance
of each of the four LEDs surrounding the Print button is
described in the table below. A more complete description of the
LEDs can be found in Chapter 2.
Control LEDs
LED name Light Color Symbol Function
Power Green Power indicator.
Ready/Data Green Printer ready.
Error Red Error indicator.
Ready-to-Work
™ Blue Intermec Ready-to-Work™
indicator.

Intermec EasyCoder PD41 Specifications

General

Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Standard interfaces	RS-232, USB 2.0
Internal memory	16 MB
Power requirements	100-240 VAC ±10%, 45-65 Hz
Media thickness	2.3 - 9.8 mm
Maximum label width	104 mm
Maximum label length	0.15 m
Maximum roll diameter	213 mm
Maximum internal memory	1 GB
Supported network protocols	TCP/IP, LPR/LPD, FTP, BOOTP, DHCP, HTTP, SNMPv3, SMTP, SNMP-MIB II
Operating temperature (T-T)	40 - 104 °F
Operating relative humidity (H-H)	20 - 85 %

Weight and Dimensions

Depth	453 mm
Width	273 mm
Height	270 mm
Weight	13000 g
