Intermec EasyCoder PD41 User Manual

Chapter 1 — Getting Started
6 EasyCoder PD41 Printer User’s Guide
Rear View
EasyCoder PD41: Rear View
Connectors
Rear view: Connection sockets
Side door
Intake for
external
media supply
Machine
labels
I
O
Ethernet RJ-45 connector
Serial RS-232 port
USB port
Parallel IEEE 1284 port
Compact Flash slot
Power On/Off switch
AC power cord socket
MAC address label

Intermec EasyCoder PD41 Specifications

General

Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Standard interfaces	RS-232, USB 2.0
Internal memory	16 MB
Power requirements	100-240 VAC ±10%, 45-65 Hz
Media thickness	2.3 - 9.8 mm
Maximum label width	104 mm
Maximum label length	0.15 m
Maximum roll diameter	213 mm
Maximum internal memory	1 GB
Supported network protocols	TCP/IP, LPR/LPD, FTP, BOOTP, DHCP, HTTP, SNMPv3, SMTP, SNMP-MIB II
Operating temperature (T-T)	40 - 104 °F
Operating relative humidity (H-H)	20 - 85 %

Weight and Dimensions

Depth	453 mm
Width	273 mm
Height	270 mm
Weight	13000 g
