LED indicators and the Print Button
The PD41 printer can enter the following different “states”,
which in turn indicate its current mode of operation.
LED indicators
The four LED indicators will be turned on, off or flash
depending on which state the printer is in. The Power LED will
always be lit for all states except Power Off.
The blue Ready-to-Work LED shows the operational status of the
printer. In simple terms, it is lit when the printer is operational.
When the Ready-to-Work indicator is turned off, or flashes, it
indicates that the printer is not fully operational. There are a
number of conditions that can cause this behaviour; refer to
Chapter 4, “Troubleshooting” for a detailed explanation. It can
also flash when in Testmode or Extended Testmode, see
“Running Testmode” in Chapter 5.
The red Error LED will be lit or flash when an error condition
has occured. This will also cause the Ready-to-Work LED to flash
or turn off.
PD41 Printer States
State Explanation
Power Off
Upgrading Firmware is being upgraded.
TestMode See Chapter 5 for description.
Extended TestMode See Chapter 5 for description.
PUP Power-UP (starting up)
Idle
Application running Fingerprint only.
Printing
Printing (wait for LTS) Waiting for Label Taken Sensor to indicate
that label has been taken.
Paused Paused during print job
Error Error state

Intermec EasyCoder PD41 Specifications

General

Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Standard interfaces	RS-232, USB 2.0
Internal memory	16 MB
Power requirements	100-240 VAC ±10%, 45-65 Hz
Media thickness	2.3 - 9.8 mm
Maximum label width	104 mm
Maximum label length	0.15 m
Maximum roll diameter	213 mm
Maximum internal memory	1 GB
Supported network protocols	TCP/IP, LPR/LPD, FTP, BOOTP, DHCP, HTTP, SNMPv3, SMTP, SNMP-MIB II
Operating temperature (T-T)	40 - 104 °F
Operating relative humidity (H-H)	20 - 85 %

Weight and Dimensions

Depth	453 mm
Width	273 mm
Height	270 mm
Weight	13000 g
