Intermec EasyCoder PD41 User Manual

Chapter 2 — Operating the Printer
14 EasyCoder PD41 Printer User’s Guide
Loading Media
The EasyCoder PD41 can print on labels, tickets, tags and
continuous stock in various formats.
Tear-Off (straight-through) Operation
This section describes the case when media is torn off manually
against the printer’s tear bar. This method is also known as
“straight-through” printing. Different sorts of media can be used
in Tear-Off operation:
• Non-adhesive continuous stock
• Self-adhesive continuous stock with liner
• Self-adhesive labels with liner
• Tickets with gaps, with or without perforations
• Tickets with black marks, with or without perforations
Tear-Off
1
Open the side door.
2
Pull out the printhead lever and turn
it counterclockwise.
2
1

Intermec EasyCoder PD41 Specifications

General

Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Standard interfaces	RS-232, USB 2.0
Internal memory	16 MB
Power requirements	100-240 VAC ±10%, 45-65 Hz
Media thickness	2.3 - 9.8 mm
Maximum label width	104 mm
Maximum label length	0.15 m
Maximum roll diameter	213 mm
Maximum internal memory	1 GB
Supported network protocols	TCP/IP, LPR/LPD, FTP, BOOTP, DHCP, HTTP, SNMPv3, SMTP, SNMP-MIB II
Operating temperature (T-T)	40 - 104 °F
Operating relative humidity (H-H)	20 - 85 %

Weight and Dimensions

Depth	453 mm
Width	273 mm
Height	270 mm
Weight	13000 g
