Intermec EasyCoder PD41 User Manual

Chapter 2 — Operating the Printer
20 EasyCoder PD41 Printer User’s Guide
Loading Thermal Transfer Ribbon
Thermal transfer printing makes it possible to use a wide range of
receiving face materials and gives a durable printout that is less
vulnerable to fat, chemicals, heat, sunlight etc. than direct
thermal printing. Make sure to select a ribbon type that matches
the type of receiving material and set up the printer accordingly.
The EasyCoder PD41 can use transfer ribbon rolls wound with
the ink-coated side facing either outward or inward.
The ribbon is normally loaded in conjunction with a new media
roll. For clarity, however, the illustrations below do not show the
media roll. See the previous sections for information on how to
load media for your type of operation.
Loading Ribbon
1
Open the side door.
2
Pull out the printhead lever, and turn
it counterclockwise.
2
1

Intermec EasyCoder PD41 Specifications

General

Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Standard interfaces	RS-232, USB 2.0
Internal memory	16 MB
Power requirements	100-240 VAC ±10%, 45-65 Hz
Media thickness	2.3 - 9.8 mm
Maximum label width	104 mm
Maximum label length	0.15 m
Maximum roll diameter	213 mm
Maximum internal memory	1 GB
Supported network protocols	TCP/IP, LPR/LPD, FTP, BOOTP, DHCP, HTTP, SNMPv3, SMTP, SNMP-MIB II
Operating temperature (T-T)	40 - 104 °F
Operating relative humidity (H-H)	20 - 85 %

Weight and Dimensions

Depth	453 mm
Width	273 mm
Height	270 mm
Weight	13000 g
