Intermec EasyCoder PD41 User Manual

Chapter 2 — Operating the Printer
EasyCoder PD41 Printer User’s Guide 19
Peel-Off, continued
7
Push in the location indicated above
to bring out the label-taken sensor.
8
Turn the Label-Taken Sensor (LTS) to a
fully horizontal position.
9
Close the side door.
10
Press the Print button to feed the
media.

Intermec EasyCoder PD41 Specifications

General

Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Standard interfaces	RS-232, USB 2.0
Internal memory	16 MB
Power requirements	100-240 VAC ±10%, 45-65 Hz
Media thickness	2.3 - 9.8 mm
Maximum label width	104 mm
Maximum label length	0.15 m
Maximum roll diameter	213 mm
Maximum internal memory	1 GB
Supported network protocols	TCP/IP, LPR/LPD, FTP, BOOTP, DHCP, HTTP, SNMPv3, SMTP, SNMP-MIB II
Operating temperature (T-T)	40 - 104 °F
Operating relative humidity (H-H)	20 - 85 %

Weight and Dimensions

Depth	453 mm
Width	273 mm
Height	270 mm
Weight	13000 g
