Intermec EasyCoder PD41 User Manual

Chapter 5 — Setting up the Printer
48 EasyCoder PD41 Printer User’s Guide
The functions 7a-7e are described on the next page.
Extended Testmode: Selecting Function
Step
Data/
Ready Error RtW Button Comment
3 flash flash flash 0 LEDs flash fast four times,
in four-second intervals.
4 flash Lower the printhead.
5 1 Press the Print button and
hold.
6 Release the button when LED combination corresponding to
your choice of function flashes. Then see corresponding
function table below.
7a001 Testfeed Mode Slow
function
7b 0 1 0 Test Label function.
7c 0 1 1 Dump mode function.
7d 1 0 0 Factory default function.
7e111 Exit Extended Testmode.
Extended Testmode: 7a - Testfeed Mode Slow Function
Step
Data/
Ready
Error RtW Button Comment
7a 1 LEDs flash once per
second.
1 Tap the Print button to
start Testfeed (Mode slow).
Test label is printed.
1LEDs flash once per
second.
Press Print button and hold it to exit Test Label function and return to
Step 6.

Intermec EasyCoder PD41 Specifications

General

Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Standard interfaces	RS-232, USB 2.0
Internal memory	16 MB
Power requirements	100-240 VAC ±10%, 45-65 Hz
Media thickness	2.3 - 9.8 mm
Maximum label width	104 mm
Maximum label length	0.15 m
Maximum roll diameter	213 mm
Maximum internal memory	1 GB
Supported network protocols	TCP/IP, LPR/LPD, FTP, BOOTP, DHCP, HTTP, SNMPv3, SMTP, SNMP-MIB II
Operating temperature (T-T)	40 - 104 °F
Operating relative humidity (H-H)	20 - 85 %

Weight and Dimensions

Depth	453 mm
Width	273 mm
Height	270 mm
Weight	13000 g
