Intermec EasyCoder PD41 User Manual

Chapter 5 — Setting up the Printer
EasyCoder PD41 Printer User’s Guide 49
Extended Testmode: 7b - Test Label Function
Step
Data/
Ready Error RtW Button Comment
7b 1 LEDs flash once per
second.
1 Tap the Print button, once
for each of 7test labels.
Press Print button and hold it to exit Testfeed Mode Slow function,
and return to step 6.
Extended Testmode: 7c - Dumpmode Function
Step
Data/
Ready
Error RtW Button Comment
7c 1 1 LEDs flash once per
second.
1 Tap the Print button to
start Dumpmode.
The printer will autohunt the communucation ports.
Tap the button to exit.
Press >1 second to save dumpmode info.
11 LEDs flash once per
second.
Press button and hold it to exit this function and return to Step 6.
Extended Testmode: 7d - Factory Default Function
Step
Data/
Ready Error RtW Button Comment
7d 1 LEDs flash once per
second.
Lift the printhead, tap the Print button, and lower the printhead.
LEDs will flash.
Tap the button. Printer will start resetting to factory defaults. This is
indicated by scrolling LEDs.
1 LED flashes once per
second, indicating factory
default reset is done.

Intermec EasyCoder PD41 Specifications

General

Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Standard interfaces	RS-232, USB 2.0
Internal memory	16 MB
Power requirements	100-240 VAC ±10%, 45-65 Hz
Media thickness	2.3 - 9.8 mm
Maximum label width	104 mm
Maximum label length	0.15 m
Maximum roll diameter	213 mm
Maximum internal memory	1 GB
Supported network protocols	TCP/IP, LPR/LPD, FTP, BOOTP, DHCP, HTTP, SNMPv3, SMTP, SNMP-MIB II
Operating temperature (T-T)	40 - 104 °F
Operating relative humidity (H-H)	20 - 85 %

Weight and Dimensions

Depth	453 mm
Width	273 mm
Height	270 mm
Weight	13000 g
