Intermec EasyCoder PD41 User Manual

Chapter 2 — Operating the Printer
EasyCoder PD41 Printer User’s Guide 17
Peel-Off (Self-Strip) Operation
This section describes the case when self-adhesive labels are
separated from the liner immediately after printing. The same
procedure is followed when installing media for Batch Takeup,
with the difference that both label and liner is rewound, and the
label-taken sensor is not used. These modes of operation require
an optional internal rewinder unit, see Appendix F, “Options.”
This is also known as self-strip operation. The label-taken sensor
can hold the printing of the next label in a batch until the present
label has been removed. Only self-adhesive labels with liner can
be used in peel-off operation.
Peel-Off
1
Remove the front cover.
2
Open the cover, mount the media roll,
and route the media through the
media feed rods.

Intermec EasyCoder PD41 Specifications

General

Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Standard interfaces	RS-232, USB 2.0
Internal memory	16 MB
Power requirements	100-240 VAC ±10%, 45-65 Hz
Media thickness	2.3 - 9.8 mm
Maximum label width	104 mm
Maximum label length	0.15 m
Maximum roll diameter	213 mm
Maximum internal memory	1 GB
Supported network protocols	TCP/IP, LPR/LPD, FTP, BOOTP, DHCP, HTTP, SNMPv3, SMTP, SNMP-MIB II
Operating temperature (T-T)	40 - 104 °F
Operating relative humidity (H-H)	20 - 85 %

Weight and Dimensions

Depth	453 mm
Width	273 mm
Height	270 mm
Weight	13000 g
