Appendix A — Technical Data
54 EasyCoder PD41 Printer User’s Guide
Printer Specifications
Printer Specifications Table
Physical Dimensions
Dimensions (WxLxH) 276 x 454.4 x 283.0 mm
(10.85 x 17.9 x 11.2 inches)
Weight (excl. media) 13 kg (28.7 pounds)
Power Supply
Input Rating 100-240 VAC, 2-1 A, 50/60 Hz
Power Consumption • Stand-by : 12W
• Normal operation/printing: 80W
• Peak: 250W
Printing
Print Technique Direct Thermal/Thermal Transfer
Printhead Resolutions 8 dots/mm (203.2 dpi) or
11.81 dots/mm (300dpi)
Print Speed
8 dots/mm (203 dpi)
11.8 dots/mm (300dpi)
50.8 to 152.4 mm/sec . (2 to 6 in./sec.)
50.8 to 101.6 mm/sec. (2 to 4 in./sec.)
Print Width Max.
8 dots/mm (203 dpi)
11.8 dots/mm (300dpi)
104 mm (4.09 in.)
105.7 mm (4.16 in.)
Print Length Max.
8 dots/mm (203 dpi)
11.8 dots/mm (300dpi)
Fingerprint
1270 mm (50 in.)
558.2 mm (22 in.)
IPL
600 mm (23 in.)
406.4 mm (16 in.)
Modes of Operation
Tear-Off (Straight-
through)
Yes
Cut-off Option with cutter
Peel-Off (self-strip) Option with internal
rewinder
Firmware (Fingerprint)
Operating System Fingerprint v10.0.X Includes Direct
Protocol
Smooth Fonts TrueType and TrueDoc fonts

Intermec EasyCoder PD41 Specifications

General

Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Standard interfaces	RS-232, USB 2.0
Internal memory	16 MB
Power requirements	100-240 VAC ±10%, 45-65 Hz
Media thickness	2.3 - 9.8 mm
Maximum label width	104 mm
Maximum label length	0.15 m
Maximum roll diameter	213 mm
Maximum internal memory	1 GB
Supported network protocols	TCP/IP, LPR/LPD, FTP, BOOTP, DHCP, HTTP, SNMPv3, SMTP, SNMP-MIB II
Operating temperature (T-T)	40 - 104 °F
Operating relative humidity (H-H)	20 - 85 %

Weight and Dimensions

Depth	453 mm
Width	273 mm
Height	270 mm
Weight	13000 g
