Intermec EasyCoder PD41 User Manual

Appendix B — Media Specifications
66 EasyCoder PD41 Printer User’s Guide
Tickets with Black Mark
* This is the print length limit set by memory constraints.
Paper Type Setup
• Tickets with Mark
a: Media Width
Maximum: 118.0 mm 4.65 inches
Minimum: 25.0 mm 1.00 inches
b: Copy Length Fingerprint IPL
8 dots/mm (203 dpi)
Maximum: 1270 mm (50 in.)* 600 mm (23 in.)
Minimum: 6 mm (0.2 in.) 6 mm (0.2 in.)
11.81 dots/mm (300 dpi)
Maximum: 558.8 mm (22 in.)* 406.4 mm (16 in.)
Minimum: 6 mm (0.2 in.) 6 mm (0.2 in.)
c: Detection Position
Variable: 0 to 57 mm 0 to 2.24 inches
d: Black Mark Width
The detectable width of the black mark should be at least 5.0 mm (0.2
inches) on either side of the Label Gap Sensor detection point.
e: Black Mark Length
Maximum: 25.0 mm 0.98 inches
Minimum: 3 mm 0.12 inches
Common: 5 mm 0.2 inches
f: Black Mark Y-Position
It is recommended that you place the black mark as close to the front
edge of ticket as possible and use a negative Stop Adjust value to
control the media feed, so the tickets can be properly torn off.

Intermec EasyCoder PD41 Specifications

General

Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Standard interfaces	RS-232, USB 2.0
Internal memory	16 MB
Power requirements	100-240 VAC ±10%, 45-65 Hz
Media thickness	2.3 - 9.8 mm
Maximum label width	104 mm
Maximum label length	0.15 m
Maximum roll diameter	213 mm
Maximum internal memory	1 GB
Supported network protocols	TCP/IP, LPR/LPD, FTP, BOOTP, DHCP, HTTP, SNMPv3, SMTP, SNMP-MIB II
Operating temperature (T-T)	40 - 104 °F
Operating relative humidity (H-H)	20 - 85 %

Weight and Dimensions

Depth	453 mm
Width	273 mm
Height	270 mm
Weight	13000 g
