Intermec EasyCoder PD41 User Manual

Chapter 5 — Setting up the Printer
46 EasyCoder PD41 Printer User’s Guide
Testmode: Activating
Step
Data/
Ready Error RtW Button Comment
1 1 Make sure the printhead
lever is lowered. Press and
hold the Print button and
switch the printer On.
Testmode is activated after
10 seconds.
2 1 1 1 LEDs flash fast one at a time.
Keep button pressed.
Testmode: Selecting Media Type
Step
Data/
Ready
Error RtW Button Comment
3 Release the button when LED corresponding to your media
type flashes
3a 1 0 Labels with gaps.
3b 1 0 Ticket with mark.
3c 1 0 Variable length strip.
4 The printer will automatically perform a sensor calibration
(Testfeed) according to your selection, and will select thermal
transfer printing if ribbons is installed, otherwise direct thermal.
Testmode: Printing Test Labels
Step
Data/
Ready
Error RtW Button Comment
5 The printer will then print four test labels after the testfeed in
step 4. To skip any test labels tap the button.

Intermec EasyCoder PD41 Specifications

General

Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Standard interfaces	RS-232, USB 2.0
Internal memory	16 MB
Power requirements	100-240 VAC ±10%, 45-65 Hz
Media thickness	2.3 - 9.8 mm
Maximum label width	104 mm
Maximum label length	0.15 m
Maximum roll diameter	213 mm
Maximum internal memory	1 GB
Supported network protocols	TCP/IP, LPR/LPD, FTP, BOOTP, DHCP, HTTP, SNMPv3, SMTP, SNMP-MIB II
Operating temperature (T-T)	40 - 104 °F
Operating relative humidity (H-H)	20 - 85 %

Weight and Dimensions

Depth	453 mm
Width	273 mm
Height	270 mm
Weight	13000 g
