Intermec EasyCoder PD41 User Manual

Chapter 1 — Getting Started
EasyCoder PD41 Printer User’s Guide 3
2 Check that no visible damage has occurred during
transportation. Keep the packing material in case you need to
move or reship the printer.
3 Check to make sure any options you ordered are included.
4 In addition to the options you may have ordered, the box
should contain the following:
1 – Intermec EasyCoder PD41 printer
2 – One or more country-specific power cords
3 – USB cable
4 – Empty ribbon core for thermal transfer printing
5 – High Media Edge Guide
6 – Quick Start Guide
7 – A PrinterCompanion CD containing software, this and
other related manuals
If you find any damage has occurred during transportation,
notify the carrier immediately. If the delivery is missing parts or is
otherwise incorrect, report it to the distributor.
1
2
3
4
5
6
7

Intermec EasyCoder PD41 Specifications

General

Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Standard interfaces	RS-232, USB 2.0
Internal memory	16 MB
Power requirements	100-240 VAC ±10%, 45-65 Hz
Media thickness	2.3 - 9.8 mm
Maximum label width	104 mm
Maximum label length	0.15 m
Maximum roll diameter	213 mm
Maximum internal memory	1 GB
Supported network protocols	TCP/IP, LPR/LPD, FTP, BOOTP, DHCP, HTTP, SNMPv3, SMTP, SNMP-MIB II
Operating temperature (T-T)	40 - 104 °F
Operating relative humidity (H-H)	20 - 85 %

Weight and Dimensions

Depth	453 mm
Width	273 mm
Height	270 mm
Weight	13000 g
