Intermec EasyCoder PD41 User Manual

Chapter 1 — Getting Started
EasyCoder PD41 Printer User’s Guide 11
2 Load media as described in Chapter 2, “Loading Media”.
3 Press and hold down the blue Print button.
4 Keep the Print button pressed down, and turn on the power
switch. After about ten seconds the printer enters Testmode
and three of the front LEDs start flashing one at a time.
5 Release the Print button at the appropriate time to establish
the media settings. Each of the LEDs (except the Power LED)
represent a media type according to the following table:
The printer will print several test labels containing the
printer’s setup parameters. It will then enter Dumpmode.
6 Press the Print button once to exit Dumpmode.
Setting the Paper Type
Flashing LED determines Media Type
Data/Ready Green Labels with gap
Error Red Tickets with black mark
Ready-to-Work Blue Continuous stock

Intermec EasyCoder PD41 Specifications

General

Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Standard interfaces	RS-232, USB 2.0
Internal memory	16 MB
Power requirements	100-240 VAC ±10%, 45-65 Hz
Media thickness	2.3 - 9.8 mm
Maximum label width	104 mm
Maximum label length	0.15 m
Maximum roll diameter	213 mm
Maximum internal memory	1 GB
Supported network protocols	TCP/IP, LPR/LPD, FTP, BOOTP, DHCP, HTTP, SNMPv3, SMTP, SNMP-MIB II
Operating temperature (T-T)	40 - 104 °F
Operating relative humidity (H-H)	20 - 85 %

Weight and Dimensions

Depth	453 mm
Width	273 mm
Height	270 mm
Weight	13000 g
