Intermec EasyCoder PD41 User Manual

Chapter 2 — Operating the Printer
EasyCoder PD41 Printer User’s Guide 25
Print Button function
State
Button pressed
< 1 s
Button pressed
> 1 s
“Double-
click”
Power Off No action
Upgrading No action
Tes t m o de See “Runn i n g Test m o d e” i n Cha p t e r 5
Extended
Te stm ode
See “Running Testmode” in Chapter 5
Idle (FP) Formfeed/
Printfeed
Testfeed
Idle (IPL) Formfeed Continuous feed
while button is
pressed
Enter Pause
mode
Application
running
Defined by application
Printing Pause print job
Paused (FP) Continue print job Cancel print job
Paused (IPL) Continue print job
Error See Chapter 4, “Troubleshooting”

Intermec EasyCoder PD41 Specifications

General

Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Standard interfaces	RS-232, USB 2.0
Internal memory	16 MB
Power requirements	100-240 VAC ±10%, 45-65 Hz
Media thickness	2.3 - 9.8 mm
Maximum label width	104 mm
Maximum label length	0.15 m
Maximum roll diameter	213 mm
Maximum internal memory	1 GB
Supported network protocols	TCP/IP, LPR/LPD, FTP, BOOTP, DHCP, HTTP, SNMPv3, SMTP, SNMP-MIB II
Operating temperature (T-T)	40 - 104 °F
Operating relative humidity (H-H)	20 - 85 %

Weight and Dimensions

Depth	453 mm
Width	273 mm
Height	270 mm
Weight	13000 g
