Intermec EasyCoder PD41 User Manual

Chapter 4 — Troubleshooting
EasyCoder PD41 Printer User’s Guide 37
5 Engage the printhead and load the ribbon.
6 Test and readjust if necessary. (Tip: Use direct thermal media
to avoid loading and unloading of ribbon multiple times.)
Adjusting Printhead Pressure
The pressure of the thermal printhead against the platen roller is
factory-adjusted. However, if the printing is weaker on one side
of the media, or if the thermal transfer ribbon starts to crease
(indicated by unprinted white streaks along the media feed
direction), it may be necessary to readjust the printhead pressure.
1 Open the side door.
2 Remove the ribbon.
3 Lift the printhead by pulling the printhead lever out and
flipping it a quarter of a turn counterclockwise.
4 Use a straight-slot screwdriver to turn the screw at the top of
the balance boxes clockwise to increase the pressure, or
counterclockwise to decrease the pressure.
Note: Before readjusting the printhead pressure, try
the to move the outer balance box as described in
Adjusting Printhead Balance procedure.
Balance
box

Intermec EasyCoder PD41 Specifications

General

Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Standard interfaces	RS-232, USB 2.0
Internal memory	16 MB
Power requirements	100-240 VAC ±10%, 45-65 Hz
Media thickness	2.3 - 9.8 mm
Maximum label width	104 mm
Maximum label length	0.15 m
Maximum roll diameter	213 mm
Maximum internal memory	1 GB
Supported network protocols	TCP/IP, LPR/LPD, FTP, BOOTP, DHCP, HTTP, SNMPv3, SMTP, SNMP-MIB II
Operating temperature (T-T)	40 - 104 °F
Operating relative humidity (H-H)	20 - 85 %

Weight and Dimensions

Depth	453 mm
Width	273 mm
Height	270 mm
Weight	13000 g
