Intermec EasyCoder PD41 User Manual

Chapter 5 — Setting up the Printer
EasyCoder PD41 Printer User’s Guide 43
Printer Startup Sequence (IPL)
1 Check for firmware binary on CompactFlash card. If so,
upgrade.
2 Check if printhead is lifted and button is pressed. If so, go to
Extended Testmode, otherwise continue startup with step 3.
3 Check to see if button is pressed. If so, go to Testmode.
4 Continue Power-Up. Run a testfeed.
The process of entering and using Testmode and Extended
Testmode is described later in this chapter.
Note: If the CompactFlash contains an earlier
firmware version than one installed in the printer,
the printer’s firmware will be downgraded.

Intermec EasyCoder PD41 Specifications

General

Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Standard interfaces	RS-232, USB 2.0
Internal memory	16 MB
Power requirements	100-240 VAC ±10%, 45-65 Hz
Media thickness	2.3 - 9.8 mm
Maximum label width	104 mm
Maximum label length	0.15 m
Maximum roll diameter	213 mm
Maximum internal memory	1 GB
Supported network protocols	TCP/IP, LPR/LPD, FTP, BOOTP, DHCP, HTTP, SNMPv3, SMTP, SNMP-MIB II
Operating temperature (T-T)	40 - 104 °F
Operating relative humidity (H-H)	20 - 85 %

Weight and Dimensions

Depth	453 mm
Width	273 mm
Height	270 mm
Weight	13000 g
