INVT Goodrive350 IP55 User Manual

Goodrive350 IP55 High-ingress Protection Series VFD Function parameter list
-155-
Function
code
Name
Description
Default
value
Modify
P05.46
Correspondin
g setting of
lower limit
frequency of
HDIB
-300.0%–300.0%
0.0%
○
P05.47
Upper limit
frequency of
HDIB
P05.45–50.000kHz
50.000
kHz
○
P05.48
Correspondin
g setting of
upper limit
frequency of
HDIB
-300.0%–300.0%
100.0%
○
P05.49
HDIB
frequency
input filter time
0.000s–10.000s
0.030s
○
P05.50
AI1 input
signal type
0–1
0: Voltage type
1: Current type
Note: You can set the AI1 input signal type
through the corresponding function code.
0
◎
P05.51–
P05.52
Reserved
/
/
/
P06––Output terminals
Function
code
Name
Description
Default
value
Modify
P06.00
HDO output type
0: Open collector high-speed pulse output: Max.
frequency of the pulse is 50.00kHz. For details
about the related functions, see P06.27–P06.31.
1: Open collector output: For details about the
related functions, see P06.02.
0
◎
P06.01
Y output
selection
0: Invalid
1: In running
2: In forward running
3: In reverse running
4: In jogging
5: VFD fault
6: Frequency level detection FDT1
7: Frequency level detection FDT2
8: Frequency reached
9: Running in zero speed
10: Reach upper limit frequency
11: Reach lower limit frequency
12: Ready to run
13: In pre-exciting
0
○
P06.02
HDO output
selection
0
○
P06.03
Relay RO1
output selection
1
○
P06.04
Relay RO2
output selection
5
○
