Appendix G Energy efficiency data
Table G-1 Power losses and IE class
Model
Relative loss (%)
Standby
loss (w)
IE
class
(0;25)
(0;50)
(0;100)
(50;25)
(50;50)
(50;100)
(90;50)
(90;100)
GD350-004G/5R5P-45-AS
1.52
1.76
2.33
1.50
1.77
2.36
1.70
2.44
6
IE2
GD350-5R5G/7R5P-45-AS
0.94
1.27
2.07
1.01
1.38
2.33
1.53
2.60
8
IE2
GD350-7R5G/011P-45-AS
0.76
0.96
1.53
0.75
0.97
1.60
0.98
1.75
10
IE2
GD350-011G/015P-45-AS
0.61
0.84
1.55
0.61
1.04
1.97
0.99
2.16
10
IE2
GD350-015G/018P-45-AS
0.56
0.78
1.42
0.56
0.78
1.46
0.80
1.60
10
IE2
GD350-018G/022P-45-AS
0.51
0.70
1.26
0.52
0.74
1.38
0.71
1.36
14
IE2
GD350-022G/030P-45-AS
0.58
0.80
1.37
0.64
0.87
1.59
0.94
1.71
11
IE2
GD350-030G/037P-45-AS
0.53
0.68
1.32
0.64
0.73
1.54
0.83
1.65
14
IE2
GD350-037G/045P-45-AS
1.02
1.24
1.92
1.10
1.38
2.16
1.49
2.37
20
IE2
GD350-045G/055P-45-AS
0.92
1.12
2.02
1.03
1.26
1.86
1.38
1.95
21
IE2
GD350-055G/075P-45-AS
0.53
0.73
1.38
0.61
0.83
1.47
0.88
1.47
21
IE2
GD350-075G/090P-45-AS
0.44
0.61
1.12
0.51
0.69
1.29
0.76
1.42
22
IE2
GD350-075G/090P-45-AS-B
0.44
0.61
1.12
0.51
0.69
1.29
0.76
1.42
22
IE2
GD350-090G/110P-45-AS
0.42
0.59
1.15
0.47
0.65
1.29
0.90
1.48
25
IE2
GD350-090G/110P-45-AS-B
0.42
0.59
1.15
0.47
0.65
1.29
0.90
1.48
25
IE2
GD350-110G-45-AS
0.66
0.86
1.53
0.79
1.01
1.77
1.12
1.93
28
IE2
GD350-110G-45-AS-B
0.66
0.86
1.53
0.79
1.01
1.77
1.12
1.93
28
IE2
Table G-2 Rated specifications
Model
Apparent
power
(kVA)
Rated
output
power (kW)
Rated
output
current (A)
Max.
working
temperature
(°C )
Rated power
frequency
(Hz)
Rated
power
voltage
(V)
GD350-004G/5R5P-45-AS
6.2
4
9.5
50°C , derate
1% for every
increase of
1°C if the
temperature
exceeds 40°C
50Hz/60Hz,
allowed
range:
47-63Hz
3PH 380V
GD350-5R5G/7R5P-45-AS
9.2
5.5
14
GD350-7R5G/011P-45-AS
12.2
7.5
18.5
GD350-011G/015P-45-AS
16.4
11
25
GD350-015G/018P-45-AS
21.0
15
32
GD350-018G/022P-45-AS
25.0
18.5
38
GD350-022G/030P-45-AS
29.6
22
45
