INVT Goodrive350 IP55 User Manual

Goodrive350 IP55 High-ingress Protection Series VFD Function parameter list
-220-
Function
code
Name
Description
Default
value
Modify
setup of spindle
spindle zero point will be the sum of P22.03 and
P22.15.
Setting range: 0–39999
P22.16
Reserved
/
/
/
P22.17
Reserved
/
/
/
P22.18
Rigid tapping
selection
0x00–0x31
Ones: Enable/disable
0: Disable
1: Enable
Tens: Analog port selection
0: Invalid
1: AI1
2: AI2
3: AI3
0x00
◎
P22.19
Analog filter time
of rigid tapping
0.0ms–1000.0ms
1.0ms
○
P22.20
Max. frequency
of rigid tapping
0.00–400.00Hz
50.00Hz
○
P22.21
Corresponding
frequency of
analog zero drift
of rigid tapping
0.00–10.00Hz
0.00Hz
○
P22.22–
P22.24
Reserved
/
/
/
P23––Vector control of motor 2
Function
code
Name
Description
Default
value
Modify
P23.00
Speed loop
proportional gain
1
P23.00–P23.05 fit for vector control mode only.
Below switch-over frequency 1 (P23.02), the
speed loop PI parameters are P23.00 and
P23.01. Above switch-over frequency 2
(P23.05), the speed loop PI parameters are
P23.03 and P23.04; in between them, the PI
parameters are obtained by linear variation
between two groups of parameters, as shown in
the figure below.
20.0
○
P23.01
Speed loop
integral time 1
0.200s
○
P23.02
Switch over low
point frequency
5.00Hz
○
P23.03
Speed loop
proportional gain
2
20.0
○
P23.04
Speed loop
integral time 2
0.200s
○
P23.05
Switch over high
point frequency
10.00Hz
○
