INVT Goodrive350 IP55

Goodrive350 IP55 High-ingress Protection Series VFD Dimension drawings
-341-
C.3 Dimensions of VFDs
Wall-mounting dimensions
Figure C-2 Wall-mounting diagram of VFDs of 004G/5R5P–037G/045P
W1
W2
H2
H1
D1
Table C-1 Wall-mounting dimensions of VFDs (unit: mm)
VFD model
W1
W2
H1
H2
D1
Installation
hole diameter
Fixing
screw
Net
weight
(kg)
Gross
weight
(kg)
GD350-004G/5R5P-45-AS
196
164
403
389
212
Ø6
M5
7
8.5
GD350-5R5G/7R5P-45-AS
GD350-7R5G/011P-45-AS
223
187
475
459
250.7
Ø7
M6
13
15.4
GD350-011G/015P-45-AS
GD350-015G/018P-45-AS
GD350-018G/022P-45-AS
274
234
522
504
246
Ø7
M6
21
23.6
GD350-022G/030P-45-AS
GD350-030G/037P-45-AS
318
263
587
567
242.9
Ø9
M8
26.5
29.5
GD350-037G/045P-45-AS
