Goodrive350 IP55 High-ingress Protection Series VFD Function parameter list
-228-
Function
code
Name
Description
Default
value
Modify
frequency of
HDI3
kHz
P25.38
Corresponding
setting of upper
limit frequency of
HDI3
-300.0%–300.0%
100.0%
â—‹
P25.39
HDI3 frequency
input filter time
0.000s–10.000s
0.030s
â—‹
P25.40
AI3 input signal
type
Range: 0–1
0: Voltage type
1: Current type
0
â—‹
P25.41
AI4 input signal
type
Range: 0–1
0: Voltage type
1: Current type
0
â—‹
P25.42–
P25.45
Reserved
/
/
/
P26––Output functions of expansion I/O card
Function
code
Name
Description
Default
value
Modify
P26.00
HDO2 output
type
0: Open collector high-speed pulse output
1: Open collector output
0
â—Ž
P26.01
HDO2 output
selection
The same with P06.01.
0
â—‹
P26.02
Y2 output
selection
0
â—‹
P26.03
Y3 output
selection
0
â—‹
P26.04
Relay RO3
output selection
0
â—‹
P26.05
Relay RO4
output selection
0
â—‹
P26.06
Relay RO5
output selection
0
â—‹
P26.07
Relay RO6
output selection
0
â—‹
P26.08
Relay RO7
output selection
0
â—‹
P26.09
Relay RO8
output selection
0
â—‹
P26.10
Relay RO9
output selection
0
â—‹
P26.11
Relay RO10
output selection
0
â—‹
