INVT Goodrive350 IP55 User Manual

Goodrive350 IP55 High-ingress Protection Series VFD Optional peripheral accessories
-353-
Field identifier
Field description
F
Filter application environment
A: Environment Category I (IEC61800-3), C1 (EN 61800-3)
B: Environment Category I (IEC61800-3), C2 (EN 61800-3)
C: Environment Category II (IEC61800-3), C3 (EN 61800-3)
Table D-7 Models of filters
VFD model
Input filter
Output filter
GD350-004G/5R5P-45-AS-B
FLT-P04016L-B
FLT-L04016L-B
GD350-5R5G/7R5P-45-AS-B
GD350-7R5G/011P-45-AS-B
FLT-P04032L-B
FLT-L04032L-B
GD350-011G/015P-45-AS-B
GD350-015G/018P-45-AS-B
FLT-P04045L-B
FLT-L04045L-B
GD350-018G/022P-45-AS-B
GD350-022G/030P-45-AS-B
FLT-P04065L-B
FLT-L04065L-B
GD350-030G/037P-45-AS-B
GD350-037G/045P-45-AS-B
FLT-P04100L-B
FLT-L04100L-B
GD350-045G/055P-45-AS
GD350-045G/055P-45-AS-B
GD350-055G/075P-45-AS
FLT-P04150L-B
FLT-L04150L-B
GD350-055G/075P-45-AS-B
GD350-075G/090P-45-AS
GD350-075G/090P-45-AS-B
GD350-090G/110P-45-AS
FLT-P04240L-B
FLT-L04240L-B
GD350-090G/110P-45-AS-B
GD350-110G-45-AS
GD350-110G-45-AS-B
Note:
1. The input EMI meets the C2 requirements after an input filter is configured.
2. The preceding table describes external accessories. You need to specify the ones you
choose when purchasing accessories.
D.8 Brake system
D.8.1 Brake component selection
When a VFD driving a high-inertia load decelerates or needs to decelerate abruptly, the motor
runs in the power generation state and transmits the load-carrying energy to the DC circuit of
the VFD, causing the bus voltage of the VFD to rise. If the bus voltage exceeds a specific
value, the VFD reports an overvoltage fault. To prevent this from happening, you need to
configure brake components.
 The design, installation, commissioning, and operation of the device must be
performed by trained and qualified professionals.
 Follow all the "Warning" instructions during the operation. Otherwise, major
physical injuries or property loss may be caused.
