Goodrive350 IP55 High-ingress Protection Series VFD Function parameter list
-165-
Input terminal
state at 2nd-last
fault
Output terminal
status at
2nd-last fault
P08––Enhanced functions
See P00.11 and P00.12 for detailed definitions.
The Goodrive350 IP55 high-ingress protection
VFD defines four groups of
acceleration/deceleration time, which can be
selected by multi-function digital input terminal
(P05 group). The acceleration/deceleration time
of the VFD is the first group by default.
Setting range: 0.0–3600.0s
Running
frequency of
jogging
This function code is used to define the
reference frequency of the VFD during jogging.
Setting range: 0.00Hz–P00.03 (max. output
frequency)
Acceleration
time of jogging
Jogging acceleration time is the time needed for
the VFD to accelerate from 0Hz to max. output
frequency (P00.03).
Jogging deceleration time is the time needed
from decelerating from the max. output
frequency (P00.03) to 0Hz.
Setting range: 0.0–3600.0s
Deceleration
time of jogging
When the set frequency is within the range of
jump frequency, the VFD will run at the
boundary of jump frequency.
The VFD can avoid mechanical resonance point
by setting the jump frequency, and three jump
frequency points can be set. If the jump
frequency points are set to 0, this function will be
invalid.
Jump frequency
amplitude 1
Jump frequency
amplitude 2
Jump frequency
amplitude 3
