Goodrive350 IP55 High-ingress Protection Series VFD Function parameter list
-172-
Function
code
Name
Description
Default
value
Modify
P08.61
AI3
disconnection
detection
threshold
0–100%
0
â—‹
P08.62
Output current
filter time
0.000–10.000s
0.000s
â—‹
P08.63
Output torque
filter times
0–8
8
â—‹
P09––PID control
Function
code
Name
Description
Default
value
Modify
P09.00
PID reference
source
When frequency command (P00.06, P00.07) is
set to 7, or channel of voltage setup (P04.27) is
set to 6, the VFD running mode is process PID
control.
This parameter determines the target reference
channel of process PID.
0: Set by P09.01
1: AI1
2: AI2
3: AI3
4: High-speed pulse HDIA
5: Multi-step
6: Modbus/Modbus TCP communication
7: PROFIBUS/CANopen/DeviceNet
communication
8: Ethernet communication
9: High-speed pulse HDIB
10: EtherCAT/PROFITNET/Ethernet IP
communication
11: Programmable expansion card
12: Reserved
The set target value of process PID is relative
value, the set 100% corresponds to 100% of the
feedback signal of controlled system.
The system operates based on the relative value
(0–100.0%)
0
â—‹
P09.01
PID digital
setting
Users need to set this parameter when P09.00
is set to 0, the reference value of this parameter
is the feedback variable of the system.
Setting range: -100.0%–100.0%
0.0%
â—‹
P09.02
PID feedback
source
This parameter is used to select PID feedback
channel.
0: AI1
1: AI2
0
â—‹
