INVT Goodrive350 IP55

Goodrive350 IP55 High-ingress Protection Series VFD Function parameter list
-194-
Function
code
Name
Description
Default
value
Modify
PZD8
P14.67
Mapped function
code of sent
PZD9
0x0000–0xFFFF
0x0000
○
P14.68
Mapped function
code of sent
PZD10
0x0000–0xFFFF
0x0000
○
P14.69
Mapped function
code of sent
PZD11
0x0000–0xFFFF
0x0000
○
P14.70
Mapped function
code of sent
PZD12
0x0000–0xFFFF
0x0000
○
P15––Functions of communication expansion card 1
Function
code
Name
Description
Default
value
Modify
P15.00
Reserved
P15.01
Module address
0–127
2
◎
P15.02
Received PZD2
0–31
0: Invalid
1: Set frequency (0–Fmax. Unit: 0.01Hz)
2: PID reference (-1000–1000, in which 1000
corresponds to 100.0%)
3: PID feedback (-1000–1000, in which 1000
corresponds to 100.0%)
4: Torque setting (-3000–+3000, in which
1000 corresponds to 100.0% of the motor
rated current)
5: Setting of the upper limit of forward running
frequency (0–Fmax. Unit: 0.01 Hz)
6: Setting of the upper limit of reverse running
frequency (0–Fmax. Unit: 0.01 Hz)
7: Upper limit of electromotive torque (0–
3000, in which 1000 corresponds to 100.0% of
the motor rated current)
8: Upper limit of braking torque (0–3000, in
which 1000 corresponds to 100% of the motor
rated current)
9: Virtual input terminal command (Range:
0x000–0x3FF, corresponding to
S8/S7/S6/S5/HDIB/HDIA/S4/S3/S2/S1)
10: Virtual output terminal command (Range:
0x00–0x0F, corresponding to
0
○
P15.03
Received PZD3
0
○
P15.04
Received PZD4
0
○
P15.05
Received PZD5
0
○
P15.06
Received PZD6
0
○
P15.07
Received PZD7
0
○
P15.08
Received PZD8
0
○
P15.09
Received PZD9
0
○
P15.10
Received PZD10
0
○
P15.11
Received PZD11
0
○
P15.12
Received PZD12
0
○
