Goodrive350 IP55 High-ingress Protection Series VFD Product Overview
-10-
Supports two groups of motor parameters to control motor
switchover.
Terminal analog input
resolution
Terminal digital input
resolution
2 inputs, AI1: 0–10V/0–20mA; AI2: -10–10V
1 output, AO1: 0–10V /0–20mA
Four regular inputs; max. frequency: 1kHz; internal
impedance: 3.3kΩ
Two high-speed inputs; max. frequency: 50kHz; supports
quadrature encoder input; with speed measurement
function
One high-speed pulse output; max. frequency: 50kHz
One Y terminal open collector output
Two programmable relay outputs
RO1A NO, RO1B NC, RO1C common port
RO2A NO, RO2B NC, RO2C common port
Contact capacity: 3A/AC250V, 1A/DC30V
Three extension interfaces: SLOT1, SLOT2, SLOT3
Expandable PG card, programmable expansion card,
communication card, I/O card, etc
Support wall-mounting and flange-mounting
Operation ambient
temperature
Ingress protection
rating
Built-in brake units are included in the standard
configuration of 37kW or lower VFDs. VFDs of 45–110kW
support optional built-in brake units. A VFD model with
built-in brake unit ends with "-B", for example,
GD350-045G/055P-45-AS-B.
Conducted emissions of all 380V models meet the
requirements of C3 in the IEC/EN 61800-3 standard.
External filter is optional: Conducted emission can meet the
requirements of C2 in the IEC/EN 61800-3 standard.
Note: It is required to observe the EMC compliance
required by the appendix of the manual. The motor and
motor cables shall be selected based on technical
requirements specified in the appendix of the manual.
