INVT Goodrive350 IP55

Goodrive350 IP55 High-ingress Protection Series VFD Function parameter list
-202-
Function
code
Name
Description
Default
value
Modify
P17.02
Ramps reference
frequency
Display current ramps reference frequency of
the VFD.
Range: 0.00Hz–P00.03
0.00Hz
●
P17.03
Output voltage
Display current output voltage of the VFD.
Range: 0–1200V
0V
●
P17.04
Output current
Display the valid value of current output
current of the VFD.
Range: 0.0–5000.0A
0.0A
●
P17.05
Motor speed
Display current motor speed.
Range: 0–65535RPM
0 RPM
●
P17.06
Torque current
Display current torque current of the VFD.
Range: -3000.0–3000.0A
0.0A
●
P17.07
Exciting current
Display current exciting current of the VFD.
Range: -3000.0–3000.0A
0.0A
●
P17.08
Motor power
Display current motor power; 100% relative to
rated motor power, positive value is motoring
state, negative value is generating state.
Range: -300.0–300.0% (relative to rated
motor power)
0.0%
●
P17.09
Motor output
torque
Display current output torque of the VFD;
100% relative to rated motor torque, during
forward running, positive value is motoring
state, negative value is generating state,
during reverse running, positive value is
generating state, negative value is motoring
state.
Range: -250.0–250.0%
0.0%
●
P17.10
Estimated motor
frequency
The estimated motor rotor frequency under
open-loop vector condition.
Range: 0.00–P00.03
0.00Hz
●
P17.11
DC bus voltage
Display current DC bus voltage of the VFD.
Range: 0.0–2000.0V
0V
●
P17.12
Digital input
terminal state
Display current digital input terminal state of
the VFD.
0x00–0x3F
Corresponds to HDIB, HDIA, S4, S3, S2 and
S1 respectively
0x00
●
P17.13
Digital output
terminal state
Display current digital output terminal state of
the VFD.
0x00–0x0F
Corresponds to R02, RO1, HDO and Y1
respectively
0x00
●
P17.14
Digital adjustment
variable
Display the regulating variable by UP/DOWN
terminals of the VFD.
Range: 0.00Hz–P00.03
0.00Hz
●
