The keypad menu setup is shown as follows.
Level 1
Level 2
Level 3
Level 4
Parameter
groups
Basic parameters
P00: Basic Function
P00.xx
P01: Start/stop control
P01.xx
P03: Motor1 Vector Ctrol
P03.xx
P04: V/F Control
P04.xx
P07: HMI
P07.xx
P08: Enhanced Function
P08.xx
P09: PID Control
P09.xx
P10: PLC&Mul-stepSpCtrl
P10.xx
P11: Protection Param
P11.xx
P13: SM Ctrl Param
P13.xx
P14: Serial Comm Func
P14.xx
P21: Position Ctrl
P21.xx
P22: Spdl Positioning
P22.xx
P23: Motor 2 Vector Ctrl
P23.xx
Motor and encoder
parameters
P02: Motor 1 Param
P02.xx
P12: Motor 2 Param
P12.xx
P20: Motor 1 EEncoder
P20.xx
P24: Motor 2 Encoder
P24.xx
Factory
parameters
P99: Factory Func
P99.xx
Terminal function
parameters
P05: Input Terminals
P05.xx
P06: Output Terminals
P06.xx
P98: AIAO Calibration
P98.xx
Optional card
parameters
P15: Comm Ex-card 1
P15.xx
P16: Comm Ex-card 2
P16.xx
P25: Ex I/OCard InpFunc
P25.xx
P26: Ex I/OCard OutpFunc
P26.xx
P27: PLC Func
P27.xx
P28: Master/slave Ctrl
P28.xx
Factory
customized
parameters
P90: Tension control speed
mode
P90.xx
P91: Tension control torque
P91.xx
P92: Tension control
optimization
P92.xx
User defined
parameters
/
/
Pxx.xx
...
State monitoring
State monitoring
parameters
P07: HMI
P07.xx
P17: State Viewing Func
P17.xx
P18: CI-IpCtrlStateView
P18.xx
P19: Ex-card StateView
P19.xx
P93: Tension control state
viewing func
P93.xx
