INVT Goodrive350 IP55 User Manual

Goodrive350 IP55 High-ingress Protection Series VFD Basic Operation Instructions
-88-
Set
value
Function
Description
60
Switch to FVC control
When this terminal is valid in stop state, switch to
closed-loop vector control.
61
PID polarity switch-over
Switching the output polarity of PID, this terminal should
be used in conjunction with P09.03
66
Zero out the counter
Zero out the position counting value
67
Pulse increase
When the terminal function is valid, the pulse input is
increased according to the P21.27 pulse speed.
68
Enable pulse superimposition
When the pulse superimposition is enabled, pulse
increase and pulse decrease are effective.
69
Pulse decrease
When the terminal function is valid, the pulse input is
decreased according to the P21.27 pulse speed.
70
Electronic gear selection
When the terminal is valid, the proportional numerator is
switched to the P21.30 numerator of the 2
nd
command
ratio.
71
Switch to mater
In stopped state, if the function is valid, the master is
used.
72
Switch to slave
In stopped state, if the function is valid, the slave is used.
73
Reset roll diameter
Used to reset the roll diameter when the tension control
function is enabled.
74
Switch winding/unwinding
Used to switch winding/unwinding modes when the
tension control function is enabled.
75
Tension control pre-drive
If the terminal is valid when the tension control function is
enabled, tension control pre-drive is performed.
76
Disable roll diameter
calculation
If the terminal is valid when the tension control function is
enabled, roll diameter calculation is disabled.
77
Clear alarm display
Used to clear the alarm display when the tension control
function is enabled.
78
Manual braking of tension
control
If the terminal is valid when the tension control function is
enabled, manual braking is activated.
79
Trigger forced feeding
interrupt
If the terminal is valid when the tension control function is
enabled, a feeding interrupt signal is triggered forcibly.
80
Initial roll diameter 1
Used to select different initial roll diameters by combining
with the initial roll diameter 2 when the tension control
function is enabled.
81
Initial roll diameter 2
Used to select different initial roll diameters by combining
with the initial roll diameter 1 when the tension control
function is enabled.
82
Trigger fire mode control
In fire mode, if the terminal is valid, the fire mode control
signal is triggered.
83
Switch tension PID
parameters
Used to switch two PID parameter groups when the
tension control function is enabled. The first group is used
by default. If the terminal is valid, the second group is
used.
84–95
Reserved
/
