INVT IPE300 Series User Manual

IPE300 series engineering VFD Function parameter list
-210-
Function
code
Name
Description
Default
Modify
1: Electrical level signal
Bit 9: Position source
0: Set by P21.17
1: PROFIBUS/CANopen setting
Bit10–11: Reserved
Bit 12: Positioning curve setting (Reserved)
0: Straight line
1: S curve
P21.17
Position set in
digital mode
Used to set the position for digital positioning.
Actual position=P21.17×P21.11/P21.12
0–65535
0
○
P21.18
Positioning
speed setting
0: Set by P21.19
1: AI1
2: AI2
3: AI3
4: High-speed pulse HDIA
5: High-speed pulse HDIB
0
○
P21.19
Positioning
speed set in
digital mode
0–100.0% (of the max. frequency)
20.0%
○
P21.20
Positioning ACC
time
Used to set the ACC/DEC time in the
positioning process.
Positioning ACC time means the time needed if
the VFD speeds up from 0Hz to the max.
output frequency (P00.03).
Positioning DEC time means the time needed if
the VFD speeds down from the max. output
frequency (P00.03) to 0Hz.
P21.20 setting range: 0.01–300.00s
P21.21 setting range: 0.01–300.00s
3.00s
○
P21.21
Positioning DEC
time
3.00s
○
P21.22
Positioning
holding time
Used to se the holding time after the
destination position is reached.
Setting range: 0.000–60.000s
0.100s
○
P21.23
Origin searching
speed
0.00–50.00Hz
2.00Hz
○
P21.24
Origin bias
0–65535
0
○
