INVT IPE300 Series User Manual

IPE300 series engineering VFD Basic operation guidelines
-54-
Function
code
Name
Description
Default
of motor 2
P04.16
V/F frequency point 1
of motor 2
0.00Hz–P04.18
0.00Hz
P04.17
V/F voltage point 1 of
motor 2
0.0%–110.0%
0.0%
P04.18
V/F frequency point 2
of motor 2
P04.16–P04.20
0.00Hz
P04.19
V/F voltage point 2 of
motor 2
0.0%–110.0%
0.0%
P04.20
V/F frequency point 3
of motor 2
P04.18–P02.02 or P04.18–P02.16
0.00Hz
P04.21
V/F voltage point 3 of
motor 2
0.0%–110.0%
0.0%
P04.22
V/F slip compensation
gain of motor 2
0.0–200.0%
100.0%
P04.23
Low-frequency
oscillation control
factor of motor 2
0–100
10
P04.24
High-frequency
oscillation control
factor of motor 2
0–100
10
P04.25
Oscillation control
threshold of motor 2
0.00Hz–P00.03 (Max. output frequency)
30.00Hz
P04.26
Energy-saving run
0: Disable
1: Automatic energy-saving run
0
P04.27
Voltage setting
channel
0: Keypad; Output voltage is determined by P04.28
1: AI1
2: AI2
3: AI3
4: HDIA
5: Multi-step running
6: PID
7: Modbus communication
8: PROFIBUS/CANopen/DeviceNet
0
