INVT IPE300 Series - Page 80

IPE300 series engineering VFD Basic operation guidelines
-69-
Function
code
Name
Description
Default
P01.02
Starting frequency hold time
0.0–50.0s
0.0s
P01.03
Braking current before start
0.0–100.0%
0.0%
P01.04
DC braking time before start
0.00–50.00s
0.00s
P01.05
ACC/DEC mode
0: Linear
1: S curve
Note: If mode 1 is selected, set P01.06,
P01.07, P01.27 and P01.28
0
P01.08
Stop mode
0: Decelerate to stop
1: Coast to stop
0
P01.09
Starting frequency of DC
braking for stop
0.00Hz–P00.03(Max. output frequency)
0.00Hz
P01.10
Wait time before DC braking
for stop
0.00–50.00s
0.00s
P01.11
DC braking current for stop
0.0–100.0%
0.0%
P01.12
DC braking time for stop
0.00–50.00s
0.00s
P01.13
FWD/REV running
deadzone time
0.0–3600.0s
0.0s
P01.14
FWD/REV running switching
mode
0: Switch at zero frequency
1: Switch at the starting frequency
2: Switch after the speed reaches the stop
speed with a delay
0
P01.15
Stop speed
0.00–100.00Hz
0.50 Hz
P01.16
Stop speed detection mode
0: Detect by the set speed (unique in space
voltage vector control mode)
1: Detect by the feedback speed
1
P01.18
Terminal-based running
command protection at
power-on
0: The terminal running command is invalid
at power-on
1: The terminal running command is valid at
power-on
0
P01.19
Action selected when
running frequency less than
frequency lower limit (valid
when frequency lower limit
greater than 0)
0: Run at the frequency lower limit
1: Stop
2: Sleep
0
P01.20
Wake-up-from-sleep delay
0.0–3600.0s (valid when P01.19 is 2)
0.0s
P01.21
Power-off restart selection
0: Disable
1: Enable
0
