R2 CAN Installation manual
The typical positive and negative messages for the three different protocols (IBIS, IRMA
(UIP) und J1708) are explained in the course of the program flow chart for installation and
in the legend in Fig. 42, p. 60.
Open all doors.
• All counting zones report open doors.
Stop the query by clicking on "B".
If the first part of the check was successfully concluded, check counting and counting
direction.
• Close all vehicle doors.
• Start IRMA-A21-Windows.
• Do not read the "Device list".
Click on the menu item "Communication". Select the communication protocol used: IBIS,
IRMA (UIP
10
) or J1708.
Set the communication options accordingly.
• Open the door.
• Mount the vehicle 5 times and alight from it through another door so that it can
be checked conclusively whether persons mounting the vehicle are really
recognized as persons mounting.
• Close the door.
Click on "B" to query the counting results. Stop the query by clicking on "B" again.
• Open the door.
• Alight from the vehicle 5 times.
Query the counting result (in case of incorrect counting results this procedure is to be
repeated no more than twice).
• Repeat this operation for all doors.
10
UIP- Universal IRMA protocol: proprietary protocol of iris-GmbH for communication between the individual passenger counting
components
