iTAS PAMSPAN501x - 4 Diagnostic and Troubleshooting; LED Status and Connection Troubleshooting

PAMSPAN501x G.SHDSL.bis EFM Gateway
-107
4
4
D
D
i
i
a
a
g
g
n
n
o
o
s
s
t
t
i
i
c
c
a
a
n
n
d
d
T
T
r
r
o
o
u
u
b
b
l
l
e
e
s
s
h
h
o
o
o
o
t
t
i
i
n
n
g
g
We could simply judge whether connection is correct or incorrect from the status of LED.
Please refer to the list below for status of connection.
Description Suggestion
Make sure Power LED, Ethernet LED,
and DSL LED are lighted.
Check all connections whether ware correct, including
DSL Line, Ethernet cable and power adapter.
Ethernet LED start to become blink
yellow while RJ-45 line has just
plugged, it will turn to yellow (No
blink) while connection is
established.
If your Ethernet LED no light, make sure the RJ-45 you
using is connected properly (Please use the crossover
Ethernet cable) If the port is disabled, then the Ethernet
LED will not illuminate. User has to connect to the peer
port and enable the port via Web or console. Note: if all
the other peer ports are also disabled, then user will
only be able to enable the ports using CLI via console.
DSL LED start to become blink yellow
while DSL line has just plugged and
start to train the DSL Link, it will turn to
yellow (No blink) while connection is
established.
If the DSL LED is still blinking, is means that Router is
training the DSL Line and connection is not Established,
in this case, Please make sure your ISP User name
and password are correct or check DSL Link is
connected properly.
