PAMSPAN501x G.SHDSL.bis EFM Gateway
4
1 Introduction
Thank you for choosing the PAMSPAN501x as your broadband access solution. This
manual will help you with the setup and configuration of your product.
1.1 PAMSPAN501x Overview
The PAMSPAN501x takes advantage of the latest technology - Extended Rate Bonded
SHDSL â opening up unprecedented possibilities for symmetric transmission.
The PAMSPAN501x comes with EFM bonding or ATM m-pair bonding; higher packet
transport allows symmetric data rates of up to 5.69 Mbps, 11.38Mbps, 17.07 Mbps, or
22.76Mbps over standard 2-wire, 4-wire, 6-wire, or 8-wire telephone lines, respectively.
EFM different rates between pair 4:1 means that speed ratio of 4 between the fastest and
slowest link of a group (according to IEEE 802.-2004)
The PAMSPAN501x is a solution that enables enterprise users to enjoy long distance, high
bandwidth and symmetric data transmission.
Distance & Rate relationship Table
26 AWG_ Without Noise _ EFM mode
Line rate (kbps)
reach (feet)
192 18000 18000 18000 18000
256 18000 18000 18000 18000
384 18000 18000 18000 18000
768 16400 16400 16400 16400
2560 11500 11500 11500 11500
3072 10500 10500 10500 10500
3392 10000 10000 10000 10000
3584 9500 9500 9500 9500
3848 9400 9400 9400 9400
4096 9000 9000 9000 9000
5696 7000 7000 7000 7000
1.2
Features
î Rate and Reach Improvements
The symmetric transmission rate can be up to 5.69 Mbps, 11.38Mbps, 17.07 Mbps,
or 22.76Mbps over standard 2-wire, 4-wire, 6-wire, or 8-wire telephone lines,
respectively.
Note: When one pair fails while operating in multiple pairs mode, the connection will
still be maintained. The other pairs can still operate at the maximum rates.
