PAMSPAN501x G.SHDSL.bis EFM Gateway
13
9. In the Control Panel, double-click the Network and Dial-up Connections icon.
10. In Network and Dial-up Connections window, right-click the Network icon, and then
select Properties.
11. In the Network Properties dialog box, select TCP/IP, and then click .
12. In the TCP/IP Settings dialog box, click the radio button labeled Server assigned IP
address. Also click the radio button labeled Server assigned name server address.
13. Click twice to confirm and save your changes, and then close the Control
Panel.
2.6.6 Windows 95, 98 PCs
First, check for the IP protocol and, if necessary, install it:
1. In the Windows task bar, click the Start button, point to Settings, and then click
Control Panel.
2. Double-click the
Network
icon.
The Network dialog box displays with a list of currently installed network components.
If the list includes TCP/IP, and then the protocol has already been enabled. Skip to
step 9.
3. If TCP/IP does not display as an installed component, click .
The Select Network Component Type dialog box displays.
4. Select Protocol, and then click .
The Select Network Protocol dialog box displays.
5. Click Microsoft in the Manufacturers list box, and then click TCP/IP in the Network
Protocols list box.
6. Click to return to the Network dialog box, and then click
again.
You may be prompted to install files from your Windows 95/98 installation CD. Follow
the instructions to install the files.
7. Click to restart the PC and complete the TCP/IP installation.
Next, configure the PCs to accept IP information assigned by the PAMSPAN501X:
8. Open the Control Panel window, and then click the Network icon.
9. Select the network component labeled TCP/IP, and then click .
