the source address for packets received on this
interface. If enabled, the system will only accept
packets from valid addresses that have already
been identified.
Icmp Router Advertise The Internet Control Message Protocol for IPv4 is
a network layer Internet Protocol that reports
errors and provides other information relevant to
IP packet processing.
Real Interface The actual main interface
Name The name of this Interface
Enabled Enable or disable this interface
3.2.3.1.1 Supporting multi port router
The device permit multi port router. To configure this, user must first delete the
default services since all ports have already been created under bridged mode by
default. Then click on the LAN connection page and choose
the routed mode as shown below:
Click “Configure” to display the service creating page. Enter the data for the required
fields and then click “Apply” to create the service as shown below:
