PAMSPAN501x G.SHDSL.bis EFM Gateway
11
PAMSPAN501X LAN port. If you manually assign IP information to all your LAN PCs, you
can use the LAN Connections to update the LAN port IP address accordingly.
2.6.3 Windows ® XP PCs
1. In the Windows task bar, click the Start button, and then click Control Panel.
2. Double-click the Network Connections icon.
3. In the LAN or High-Speed Internet window, right-click on the icon corresponding to
your network interface card (NIC) and select
Properties
. (Often, this icon is labeled
Local Area Connection). The Local Area Connection dialog box displays with a list of
currently installed network items.
4. Ensure that the check box to the left of the item labeled Internet Protocol TCP/IP is
checked, and click.
5. In the Internet Protocol (TCP/IP) Properties dialog box, click the radio button
labeled Obtain an IP address automatically. Also click the radio button labeled
Obtain DNS server address automatically.
6. Click twice to confirm your changes, and close the Control Panel.
2.6.4 Windows 2000 PCs
First, check for the IP protocol and, if necessary, install it:
1. In the Windows task bar, click the Start button, point to Settings, and then click
Control Panel.
2. Double-click the
Network and Dial-up Connections
icon.
3. In the Network and Dial-up Connections window, right-click the Local Area Connection
icon, and then select Properties.
The Local Area Connection Properties dialog box displays with a list of currently
installed network components. If the list includes Internet Protocol (TCP/IP), then the
protocol has already been enabled. Skip to step 10.
4. If Internet Protocol (TCP/IP) is not displayed as an installed component, click
.
5. In the Select Network Component Type dialog box, select Protocol, and then click
.
6. Select Internet Protocol (TCP/IP) in the Network Protocols list, and then click
.
