GETTING TO KNOW YOUR VEHICLE 155
Bed Rail Tie Down Locations
There are two adjustable utility rail cleats on each side of the
bed t
hat can be used to assist in securing cargo.
Adjustable Cleat Assembly
Each utility rail cleat must be tightened down in one of the
deten
ts along either utility rail in order to keep cargo prop-
erly secured.
To move the utility rail cleat to any position on the utility rail,
t
urn
the cleat retainer nut counterclockwise, approximately
three turns. Then, pull out on the utility rail cleat and slide it
to the detent nearest the desired location. Make sure the
utility rail cleat is seated in the detent, and tighten the nut.
1 — Utility Rail Detent
2 — Cleat Retainer Nut
3 — Utility Rail Cleat
2
