106 GETTING TO KNOW YOUR VEHICLE
DOOR FRAME Door Frame Removal
NOTE:
The rear door frames must be removed first, followed by the
front
door frames.
1. Using the provided #T40 Tor
x head driver and ratchet,
loosen the Torx head fasteners located on the underside
of each door hinge (two per door).
Door Frame Torx Head Fastener Locations
WARNING!
• Do not drive your vehicle on public roads with the door
fram
e(s) removed as you will lose the protection that
they can provide. This procedure is furnished for use
during off-road operation only.
• Do not drive your vehicle on public roads with the
doors
removed as you will lose the protection that they
can provide. This procedure is furnished for use during
off-road operation only.
CAUTION!
Failure to follow these cautions may cause interior water
d
amage
, stains or mildew:
• Opening a door or lowering a window while the top is
wet
may allow water to drip into the vehicle's interior.
• Careless handling and storage of the removable door
fram
e(s) may damage the seals, causing water to leak
into the vehicle's interior.
• The door frame(s) must be positioned properly to
ensu
re sealing. Improper installation can cause water to
leak into the vehicle's interior.
